SPECIFICATIONS
Hign-concerned Chemical: None
Luminous Flux: 2000-82000
Power Source: DC
Origin: Mainland China
Certification: CCC
Certification: ce
Certification: ROHS
Certification: UL
Average Life (hrs): 50000
LED Chip Model: SMD5050
Strip type: SMD
Waterproof: Yes
Is Smart Device: YES
Color Temp(K): 6000-6500K, 4000-4500K, 2700-3000K
Occasion: LIVING ROOM
Model Number: BTF-SK6812-RGBW
LEDs Number/M: 30/60/144
Item Type: Strip
Voltage: 5V
IC Number/M: 30/60/144
Waterproof Grade: IP30, IP65, IP67
Adhensive Tape: IP30, IP65
Theoretical Power: 0.3W / LED
Pixels Controller: Arduino uno, Raspberry pi, Wifi, Bluetooth and APP pixels controller, etc
Recommend Pixels Controller: SP617E, SP630E, SP530E, WT-SPI
IC Type: SK6812 RGBW IC, 1 IC Drives 1 LED Chip
Addressable: Every LED Individually Addressable
Cuttable: Every LED is cuttable
Package Including: Only LED Lights ( No power and pixels controller )
Attention 1: Must work with Pixels Controller and 5v Power
Attention 2: Every 0.5 meter with Solder Joints
Please Pay Attention:
1. The Price is Only LED Strip, Not Included Power Supply and Pixels Controller.
2. SK6812 RGBW Must Use DC5V Power Supply and Pixels Controller to Control.
3. Every 0.5 Meter with Solder Joints, It Is Very Normal In an Electronic Product, It's Not a Quality Problem.
4. SK6812 RGBW LED Strip Can Be Cut Between Each LED To Create Custom Lengths, Do Not Bend LED Strip Sharply.
5. The 3 Pin SM Connectors of LED Strip Included: Red: VCC, White: GND, Green: DATA.
6. The LED Strip Has Adhesive Tape On The Back of PCB ( Except IP67 ). Please Make Sure Installation Surface Must Be Smooth, Clean And Dry.
7. Longer LED Strip Runs, Please Add More Power to 2 Pin Power Wire of Both Ends To Reduce Voltage Drop.
How to Choose LED Power Supply and Pixels Controller?
First, Calculated The Whole LED Strip Lights Watts.
One LED Chip is About 0.3W, If You Buy 5m 60LEDs/m ( Total LED Strip is 300 LEDs ), So 0.3W*300=90W.
Then, Choose the Right LED Power Supply.
This LED Strip is Work with DC5V Power, So 90W / 5V=18A ( At Least 18A or more ).
Finally, Choose the Right Pixels Controller You Like.
SK6812 RGBW LED Strip is Controlled By Double Data Line Pixels Controller.
So you could choose them from our store, we have IR Remote+Bluetooth APP SP617E, Bluetooth APP SP630E, Wifi APP SP530E, and Computer controller etc. ( If you can't recognize them, you could feel free to contact us, we will glad to help you ).
30, 60, 144: 30leds/m,60leds/m,144leds/m.
IP30: Non- waterproof.
IP65: Waterproof in Silicon Coating.
IP67: Waterproof in SiliconTube.
(RGBCW 6000-6500K ;RGBWW 2700-3000K ; RGBNW 4000-4500K).
The length as you choose.
LED source : 5050SMD RGBW built-in SK6812 chipset.
Voltage(DC): DC5V.
Power: 144LEDs/meter -------43.2W / Meter.
60LEDs/meter ---------18W / Meter.
30LEDs/meter ---------9W / Meter.
LED type : SMD5050.
IC type : SK6812 RGBW.
LED/per meter: 30, 60,144leds/Meter (each LED is separately controlled).
IC/per meter: 30, 60,144IC/Meter (1 IC drives 1 led chip).
Pixel /per meter: 30, 60,144Pixels/Meter.
Grey Grade: 256.
Color: RGBW (WW 2700-3000K ; CW 6000-6500K; NW 4000-4500K).
PCB color: White / Black available.
Waterproof Grade:IP30-----NON-Waterproof, IP65-----Epoxy, IP67-----silicone tube.
IP30,IP65, There is a self-adhesive tape at the back side. You can install easily.
Application:
Applicable for automobile and bicycle decoration, border or contour lighting.
Widely used for home decoration use, hotels, clubs, shopping malls.
Architectural decorative lighting, boutique atmosphere lighting.
Extensively applied in Backlighting, concealed lighting, channel letter lighting.
Emergency & security lighting, advertisement sign lighting.
Decorative lights for holiday, event, show exhibition.
